OVERVIEW

• 1. Anode voltage: 60-90kv
• 2. Anode current: 4-10mA
• 3. FOA:16*10CM, 5*5CM
• 4. Inherent filtration: 2.5mmAI
• 5. Focal spot: 0.5mm
• 6. Voxel size: 0.25,0.2,0.1,0.075mm
• 7. Scanning posture: standing
• 8. X ray emission type: pulsed
• 9. Scanning time: ≤15s
• 10. Constructuring time: ≤60s
• 11. Gray scale: 14 bit
• 12. Recommend installation space: 1900*2100*2300mm(L*W*H)
• 13. Dimension: 1560(L)*1960(W)*1733*2283(H)mm

ADVANTAGE

• 1. Multi-function panoramic
• .HD Panoramic Image
• Multi function CBCT provides variety of panoramic imaging modesincluding standard mode, child mode segment imaging, etc. to satisfy the imaging requirements of different jaw arch shapes and different examination requirement.
• .Child Model & Segment Panoramic Image
• Artificial Intelligence guided panoramic imaging:Automatic dental arch positioning based on artificial intelligence technology can improve the positioning accuracy of patients in panoramic imaging, improve image quality and avoid repeated inspections due to positioning errors
• 2. Multi-function Cephalometric
• 5 Modes: PA, LAT,Waltz position,Caldwell position and Metacarpal
• 3. Excellent lmaging
• Hi-resolution mode (75 um), it helps doing diagnosis in difficult endodontic cases
• Removing metal artifact, makes im age more dear and easy to make diagnosis
• Big FOV 16*10, it almost fit all requirement for dentist, One-time scan can construct the image for mandibular maxillar and TMJ
• 4. Easy-operated Software
• D55 has powerful algorith to construct 3D model and panoramicimage
• Output with DICOM to fit all third party software
• 5. Implant Surgery Custom Plan
• .Neural Tube checking
• Find the relationship between neural tube and third molar Check the distance between neural tube and implant in case of the implant touch neural tube
• .Simulated Implant
• DViewMartirx released new 3Dimplant simulation moduleit can measure missing tooth's width, height and bone density Also it has implant libraries, put the characteristics of implant and simulate a implant operation
• .Measurement for Bone Density
• Providing foreseeable situation reference before implant surgery
• 6. Planning for orthodontic treatment
• .Cephalometry
• 14 measure method plans Customized measure method Easy finding measure point Easy Operation
• .Analysis Trachea
• Before the orthodontic treatment designed. we can analysis trachea. it can helps dentist to plan the orthodontic treatment for some special case like OSAS.OSAHS
