Dental X-Ray Image Plate Digital Intraoral PSP Scanner

General Information

1.Effective Scan lmage Area : 0#: 22*35mm,1#: 23*39mm,2#:30*40mm,3#: 26*53mm.

2. Input Volage : 100 v - 240 v ~ ,50/60Hz 26.

3. Maximum Input Power: 145 VA

4. Supply Voltage : DC 15V 4A

5. atmospheric pressure : 70 kPa ~ 106 kPa

6. Working Environment temperature : 10 ℃ - 40 ℃

7. relative humidity : ≤93%.

8.Dimension :305 mm x220 mm x 180 mm.

9. Net Weight : 6kg.

10. Gross Weight : 7kg

Technical Parameter Display:

1. external PC and displayed by the upper computer software.

2. Operation Method: contrclled by the upper computer software.

3. Threshold Contrast: it should be able to differentiate al four hales with diameters of 1.0mn, 1.5mm, 2.0mm and 2.5mm.

4. lmage Uniformity: no greater than 2%.
